Design

  • V Design and Tooling an ISO 9001:2015 is a center which nurtures excellence and provides total Tool Design, Tool Room and Machining solutions under one roof.
  • State of-the-art Tool Room facilities under single roof has wide spectrum’s of sophisticated Machines include latest & advanced CNC Lathe, Milling, EDM & Wire Cut machines, which can cater to various requirements of the customers.
  • Modern Tool Room Facilities are indispensable for the industrial development of the Country & properly trained manpower is an asset to the nation.

Rubber Moulds

  • Our Core Competency is in Design and Development of Rubber Molds and Press Tools.
  • Rubber Molds:
  • – Flash-less Molds – Tear and Trim Grooves for easy deflashing
  • – Easy Part Ejection – 3 Plate mold with Wells for easy part ejection
  • – Air vent grooves
  • – Hardened and Tempered – Guide pillar and Guide bush
  • – Slip pins for perfect guiding of plates
  • – Perfect Design as per shrinkage

Press Tools

We are specialized in Design and Development of Press Dies

  • Blanking and Piercing dies
  • Bending dies
  • Forming dies
  • Notching Dies

About us

V

V Design and Tooling is an ISO 9001:2015 certified Design Center ,Tool Room and machining situated at Ahmednagar Industrial Area, Maharastra,India founded in 1995. Ahmednagar is an  Industrial city located 100 km from Pune and 100 km from Aurangabad. We are into Tooling and machining services. The company covers total 5000 Square striindufeet. We have full fledged design center with highly experienced and qualified Design engineers
We also have fully equipped manufacturing and Tool Room setup for Tooling and machining services.

Design Center    |    Tool Room   |    Machine Services  |    Automation

MISSION:- We are a growing company with a mission to produce high quality Product Development & tooling with state of the art machinery, design, manufacturing and production skills at a reasonable cost.

VISION:- To foster employment for uniquely skilled individuals by rebuilding and retrofitting machines that would provide technological advances in machines to increase customer’s profitability in the marketplace. To become

Services

SERVICES OVERVIEW:

  • Press Tools

  • Rubber Molds

  • Special Purpose Machines

  • Material Handling Trolley

– 3D Product Design
– 2D Detailing
– 2D & 3D Conversion
– 3D Modelling
Engineering Solutions
Reverse Engineering
Value Engineering
– Tool Reconditioning & Modification
– machine Spare Parts & Maintenance
– Lathe Chuck, Reconditioning, Chuk Jaw, Screw
– All Types of Maintenance
– Press Tool
– Jigs
– Fixtures
– Spot Welding Fixtures
– Special Purpose Gauges
– Rubber Moulds
– Injection mold
– Milling
– Turning
– Drilling
– Grinding
– VMC
– Wire Cutting
– Batch Production items
capture

Company Brochure

Company Brochure

Facility

While facilities have changed a lot over the past few decades, our ability to adapt to new challenges only grows stronger. We provide comprehensive facilities services covering nearly all multiple industries all over the world.

Our knowledge and expertise enable us to develop tailored solutions that deliver on your highest priorities. From technical challenges to daily operational support, we provide extensive capabilities designed to meet your business goals.

By combining our deep expertise with the right people on the ground, we ensure our solutions make the biggest impact on your environments

Sr. No. Machine Make Specs Qty
1 CNC Turning Jyoti Dia 200 X 600 2
2 VMC Jyoti RDX20 1000 X 500 X 500 1
3 Milling Machine Somon,Brand Spec no 2 1
4 Milling Machine HMT Spec no 2 1
5 Milling Machine HMT Spec no 2 1
6 Lathe Machine B Parmar 7 Ft 1
7 Lathe Machine Sagar Brand 7 Ft 1
8 Cylinderical Grinding Amba,Rajkot Dia 200 X 600 1
9 Hackshaw Machine Rajkot Jr x 560 2
10 Band Shaw Machine Rajkot 1
11 Surface Grinding Abwood,UK 200 X 500mm 1
12 Drilling machine Rajkot 4
13 Arc Welding Machine 1
14 Cast Iron Surface plate 600 X 400mm 1

Portfolio

Rubber Washer = 49 Cavites

Rubber Bellow Mold

PVC Pipe Gasket Rubber Mold

Rubber Mold - 9 Cavities

Air Vent Plug - Rubber Mold 100 Cavities

Anti Vibration Pad Rubber Mold

PVC Gasket - Rubber Mold - 4 Cavities

GRP Pipe Gasket Compression Mold - 4 Cavities

Vaccum Gasket - Rubber Mold

Compression Rubber Mold

O-Ring Mould - 4 Cavities

O-Ring Mould - 4 cavities

Gasket Mold - 36 cavities

Gasket Rubber mold - 36 cavities

Contact

Address

C-26, MIDC Ahmednagar.
Maharashtra. India.

Call Us

+91-9960605115, 0241-2030600
